Description

Battery charging cabinet Premium 8/5 8/5 with stacking feet, 1-phase – lockEX

Electronic smoke detector (without audible alarm), power supply in cabinet, technical ventilation, power disconnection in case of heat development, door contact switch, power disconnection in case of smoke detection and voltage-free output on the outside of the cabinet for connection to a fire alarm system, 12 V connection for e.g. accessory combination alarm unit (visual and audible)

• power supplied by 6-way socket power strip (3500 W, 16 A)
• heat dissipation by fan during charging
• charging current is interrupted if the doors are opened
• charging stops if a malfunction or accident occurs
• vents sealed with thermocouples

Fire prevention is important when charging lithium batteries. CEMO now offers a safe solution. Providing important safety equipment can minimise the consequences of these storage devices burning and significantly increase safety.

• lithium batteries in the cabinet
• early alarm in case of damage
• all relevant safety regulations for charging lithium batteries are observed
• ideal for separating batteries on charge from stored units
• can also be used as an under-table cabinet under the workbench
• certifications from the TÜV NORD Group using the latest test programme with real battery fire testing and induced gas explosions
• MPA-tested fire resistance over 60 minutes from inside to outside according to DIN EN 1363-1
• built using non-combustible, fire-resistant components
• NEW: Spring-based CEMO lockEX door locking for controlled pressure relief during explosions
• special fire prevention seals prevent flames escaping
• cold smoke-tight sealing system for openings
• transportable for positioning at the place of installation
• lockable double doors with sturdy lock and hinges
• doors painted orange, matching RAL 2004; body grey, matching RAL 7035

For more information on CEMO lockEX, please visit: www.cemo-group.com/lockex
